Applications: Large tanks and reservoirs where high flow is required.
Used for water, with models available for other liquids (consult us).
Connection type: BSP or NPT
Pilot: 1" BSP
Rod Length: 420 mm
Minimum working pressure: 0.5 kgf/cm²
Maximum working pressure: 15 kgf/cm²
This model requires a minimum working pressure of 0.5 kgf/cm² or 7.11 psi for its operation.
ATTENTION: THIS VALVE DOES NOT OPERATE UNDER THE FOLLOWING CONDITIONS:
- Lack of water in the system for a period (analyze if water shortages occur frequently).
- Supply pressure below 0.5 bar (5 meters of water column).
- Solid debris in sufficient quantity to block the piston.
Before making your purchase:
- Verify the information provided in the drawing for the chosen size and model.
- Ensure that your pressure and flow rate requirements are compatible. The valve is not suitable for pressures below 7.11 psi.
- The valve must be used with clean water at room temperature.
Additional questions can be addressed by our technical team if necessary. For other operating and application conditions, please consult us.
